Atom AMP 2
All Metal, More Power, More Fun
We built Atom Amp 2 for those who demand more. Atom Amp 2 is like Atom Amp+ on steroids. It's housed in an aluminum chassis with an easier to grip knob, featuring both 4.4mm and 6.35mm headphone jacks, failsafe DC protection, and octo-buffers pumping out more than twice the power of Atom Amp+. No noise. Front-mounted controls. Hand matched potentiometers. Custom engravable. Atom Amp 2, your new go-to headphone amp.
I honestly think that every audiophile should have a no-frills Atom 2 Amp on their desk. It’s simply that good.
You get an essentially flawless, state of the art headphone amplifier in the form of Atom 2. [. . .] Really, I can't think of anything negative to say even though I am good at that sort of thing!
Specifications
Performance
Frequency Response, 20Hz-20kHz
SINAD @ 2VRMS, 1kHz
SINAD @ 50mV, 1kHz
SNR (20-20kHz)
IMD SMPTE
Noise (20-20kHz)
Crosstalk @ 10kHz (RCA Out)
Input Impedance
Output Impedance
Channel Balance
Max Continuous Power @ 600Ω
Max Continuous Power @ 300Ω
Max Continuous Power @ 150Ω
Max Continuous Power @ 32Ω
Result
+/- 0.01dB
120 dB
93 dB
124 dB
-97 dB
1.33 μV
-101 dB
10k Ω
0.7 Ω
< 0.6 dB
143 mW (9.28VRMS)
286 mW (9.27VRMS)
570 mW (9.25VRMS)
2.65 Watts (9.22VRMS = 26Vpp)
Dimensions
Case Dimensions (including knob)
Weight
Connectivity
Headphone Outputs
Analog Inputs
Preamp Output
Configuration
Dual Gain
Volume Potentiometer Taper
Packaged Items
Atom Amp 2
16VAC Power Adapter
Description
145 x 131 x 34 mm (5.7 x 5.1 x 1.3 in)
1 lb (454 g)
___
4.4mm and 6.35mm (1/4")
RCA and 3.5mm
RCA
___
Dual Gain
Volume Potentiometer Taper
